Essential Material Transfer Techniques to Prevent Cleanroom Contamination

Imagine walking into a restaurant with questionable hygiene. You’d likely leave immediately, concerned about the potential health risks. Now, consider a pharmaceutical manufacturing facility, where the stakes are even higher, and maintaining rigorous hygiene and cleanliness is even more critical. In these facilities, a cleanroom design is key to productivity, but effective material transfer processes are equally important for controlling contamination and enhancing operational efficiency.

Methods for Material Transfer in Cleanrooms

1. Multiple Cleanroom Bag Method

This method is used during multi-stage transitions, i.e., from the outermost level to the core of the cleanroom. At each stage, the bag is placed in pass-throughs and replaced with a new one until it reaches the final level of the cleanroom. Bags are numbered and sterilized, ensuring that any potentially contaminated outer bags and microbial contaminants are removed in lower-classified areas. This prevents contaminants from migrating into the processing area.

2. Disinfection Method

This method involves using a validated disinfectant solution to spray or wipe products and packages being transported into the cleanroom. The disinfection process ensures that all areas are exposed and meet the minimum wet contact time for effective sterilization. It also regulates the types of disinfectant used and the amount dispensed. The wiping technique of moving from the cleanest area to the dirtiest area using parallel, overlapping strokes can be implemented for greater control.

3. Direct Sterilization Method

This process uses double-sided pass-through autoclaves. A complete sterilization process takes place in the autoclave, i.e., items are loaded on one side and unloaded on the other in a higher-classified area. Alternative sterilization methods may include vaporized hydrogen peroxide, ozone, dry heat ovens, or washers. The Direct Sterilization Method is regarded as the most efficient.

Key Considerations for Proper Material Transfer

1. Minimizing Particle and Microorganism Generation

Materials such as cardboard boxes and wood pallets can release unwanted particles and microorganisms into cleanroom environments and compromise the sterility and cleanliness of the facility. These materials must be strictly prohibited from entering cleanroom environments.

2. Material Compatibility with Disinfectants and Transfer Methods

Different materials require specific transfer methods. For instance, using a double-sided autoclave to transfer media plates can damage them. Thus, it is essential to select compatible methods and disinfectants that preserve the materials’ integrity.

3. Proper Storage Practices for Cleanrooms

Cleanrooms must adhere to stringent storage protocols. Storing items directly on the floor should be avoided, as the floor is often the most contaminated area. Instead, all items should have designated spots on shelving systems that are specifically designed for cleanroom environments.

4. cGMP Labeling and Storage Requirements

Items stored in cleanrooms must be properly labeled according to cGMP (current Good Manufacturing Practices) guidelines. This includes clear labeling of contents, batch numbers, and expiration dates to ensure regulatory compliance and traceability.

5. Avoiding Non-Sterile Material Contamination

Non Sterile materials, such as raw or active pharmaceutical ingredients (APIs), should only enter the cleanroom after undergoing proper sterilization processes. This is crucial for maintaining the sterile conditions required for sensitive operations.

6. Disinfecting and Using Carts in Cleanrooms

Carts are essential for transferring equipment like environmental monitoring tools within the cleanroom. To prevent contamination, the carts, especially the wheels, must be thoroughly disinfected before use. Carts that move between different areas must undergo proper cleaning and sanitation procedures.

7. Dedicated Cleanroom Carts for Controlled Material Transfer

The most efficient practice is to use dedicated cleanroom carts for transferring materials. General-use carts should never enter cleanrooms directly. Instead, materials should be transferred through cleanroom-specific carts to minimize contamination risks.

8. Efficient Waste Management

Managing waste in a clean environment is critical for avoiding contamination. Waste should be promptly removed from the cleanroom through dedicated waste pathways that are separate from clean material transfers. This prevents any cross-contamination between waste and sterile or clean items.

Other Transfer Considerations

1. Barrier Systems and Material Pass-Throughs

Barrier systems, such as pass-through chambers, are essential for preventing microbial contamination by separating areas with different cleanliness classifications. HEPA filter for laminar airflow ensures that air flows from cleaner to less clean areas, preventing reverse contamination. Pass-through chambers with HEPA filters and UV-C lighting help decontaminate materials before entering or exiting cleanrooms.

2. Decontamination Protocols for Materials

Material decontamination often involves surface sterilization using chemical agents, vaporized hydrogen peroxide (VHP), or radiation, depending on material sensitivity. For heat or chemical-sensitive items, gamma irradiation is preferred. Proper material compatibility with the decontamination method is crucial.

Personnel must follow strict protocols, including wearing cleanroom-specific garments and using sterile wipes or sprays to clean materials before entry. Standard Operating Procedures (SOPs) should define guidelines for each material type, with periodic audits ensuring compliance.

3. Pressure Differentials and Airlocks

Airlocks, designed with differential pressures, are vital for contamination control during material transfer. Positive pressure in cleanrooms prevents contaminated air inflow, while multi-stage airlocks create barriers to contaminants. Proper management of pressure gradients and vertical laminar airflow systems sweep away particles and microorganisms, reducing contamination risks.

4. Fabtech Transfer Devices

Fabtech’s material transfer devices are designed for contained product transfer across various applications, including tablet and capsule manufacturing, injectables, APIs, and other custom solutions. The selection of material transfer devices is based on:

Physical, chemical, and biological characteristics of materials
OEL (Occupational Exposure Limit) level of basic raw or processed materials during the different stages of manufacturing
Material Quantity
Ease of handling

fabtech-material-transfer-devices-manufacturing

5. Pass-Through Chambers (Pass-Through Boxes)

Pass-through chambers come in two types: static and dynamic. Static pass boxes are designed for transferring materials between rooms with the same cleanliness levels, minimizing personnel movement. They function similarly to airlocks or laminar airflow units.

On the other hand, a dynamic pass box with VHP integration, facilitates the transfer of materials from uncontrolled to controlled environments, providing greater flexibility. Both types serve the crucial purpose of reducing contamination risks. These chambers are often equipped with HEPA filtration and UV-C lighting for enhanced decontamination.

6. Dedusting Tunnel

As the name implies, a dedusting tunnel removes particulate matter from raw material containers like drums, cartons, sacks, or bags before sampling or dispensing. It uses a high-speed rolling conveyor with powerful air jets that blow across the container surfaces, removing accumulated particles. Once the de-dusting process is complete, the conveyor moves the cleaned materials out of the chamber, ready for stacking or placement in the warehouse.

7. Split Butterfly Valves

Split butterfly valves are primarily used to transport large quantities of materials during the intermediate stages of manufacturing. Split butterfly valves are made of active and passive sections with the active section always fitted onto the containment system and the passive section onto the material transfer container.

Fabtech’s split butterfly valves are used in tablet and capsule manufacturing, API, and customized containment projects for material movement conforming to various OEL requirements.

8. Rapid Transfer Ports

Rapid transfer ports RTPs consist of Alpha and Beta sections. The alpha section of the port is fitted onto the containment system while the beta section is attached seamlessly to the material transfer container. RTP solutions are used to transport small quantities for aseptic applications such as detaching pharma process vessels like aseptic filtration from a filtration isolator and docking them to filling machines, sterilization of materials in an autoclave, etc.

9. Depyrogenation Tunnel

This is an essential tool in the aseptic processing environment. It is designed to remove pyrogens (fever-causing contaminants such as endotoxins) from glassware, vials, ampoules, and other materials before they are filled with sterile products. Depyrogenation is critical for ensuring the safety and purity of injectable pharmaceutical products.

Material transfer processes are a critical element in cleanroom contamination control. Overlooking any part of this process can compromise product quality and safety, posing serious health risks.

Many pharmaceutical engineering projects have seen enhanced efficiency and productivity with Fabtech’s solutions for cleanrooms. By following stringent material transfer protocols and utilizing our advanced equipment, you can ensure the highest standards of contamination control for your project.
